Features: Long service life, excellent protective effect, easy to install and disassemble.
Place of origin: Shandong, China
Brand Name:YunJie
Material:Carbon steel
Application:Roadway Safety
Surface treatment:Hot Dippe Galvanized
Standard:AASHTO M-180
Model: w-beam
Capacity: 2500 pieces per day
Product description
Road Safety Crash Barrier is a facility used to protect the safety of vehicles and personnel on traffic roads, commonly known as w-beam guardrail, highway guardrail, steel road barrier, etc. One of the functions of Road Safety Crash Barrier is to absorb the kinetic energy of the vehicle to reduce the damage caused by a collision, and it is often used in dangerous roads.The size and model of Road Safety Crash Barrier can be customized, if you want to know more, please contact us.
Length | Width | Height | Finished thickness |
4320MM | 310MM | 85MM | 3MM |
Note: The raw material is Q235B, equivalent to ASTM A36, EN10025 S235. Yield point≥235Mpa, Tensile strength: 370-500Mpa, Elongation≥26% *Galvanizing quantity: 550g/㎡ double-sided, or 1100g/㎡ double-sided. *All sizes, galvanizing quantities and raw materials can be customized. |
What are the characteristics of the guardrail spray?
Spraying is a surface treatment method of powder spraying on parts, that is, we often talk about electrostatic powder spraying, which is the use of electrostatic generators to make plastic powder charged, adsorbed on the metal surface, and then after high temperature baking and curing, so that the powder melts and adheres to the metal surface.
Spray plastic powder mainly acrylic powder, polyester powder and so on. The advantage is that there is no need for thin material, the construction is pollution-free to the environment and non-toxic to the human body; The coating has excellent appearance quality, strong adhesion and mechanical strength; Spray curing time is short; The corrosion and wear resistance of the coating is much higher; No primer required; Simple construction, low technical requirements for workers; The cost is lower than the spray painting process. Waveform guardrail mostly uses this technology to treat the surface.
Our Advantages
